SGM61020.pdf? 2.5V to 5.5V Input Voltage Range
? Adjustable Output Voltage from 0.6V to VIN
? Up to 95% Efficiency
? Low RDSON Switches (102mΩ/57mΩ)
? Power-Save Mode for Light Load Efficiency
? 42μA (TYP) Operating Quiescent Current
? 100% Duty Cycle for Low Dropout Operation
? 1.5MHz PWM Switching Frequency
? Power Good Output (SGM61020P Only)
? Over-Current Protection
? Thermal Shutdown Protection
? Input Under-Voltage Lockout (UVLO) Protection
? -40℃ to +125℃ Operating Temperature Range
? Small Packaging:
SGM61020: Available in Green SOT-23-5
and SOT-563-6 Packages
SGM61020P: Available in a Green SOT-563-6 Package
? Low IQ: 11μA
? 2.2MHz Switching Frequency
? EN for Power Sequencing
? Wide 2.3V to 5.5V Operating Input Range
? Output Adjustable from 0.6V
? Up to 2A Output Current
? 120m? and 80m? Internal Power MOSFET Switches
? Output Discharge
? Short-Circuit Protection (SCP) with Hiccup Mode
? Stable with Low ESR Output Ceramic Capacitors
? Available in a SOT563 Package
? 100% Duty Cycle
