74LVC1G125GV.pdf? Wide Supply Voltage Range: 1.65V to 5.5V
? High Noise Immunity
? ±24mA Output Drive at VCC = 3.0V
? CMOS Low Power Consumption
? Inputs Accept Voltages Up to 5V
? Direct Interface with TTL Levels
? -40℃ to +125℃ Operating Temperature Range
? Available in a Green SC70-5 Package
? Available in the Ultra Small 0.64-mm2
? Package (DPW) With 0.5-mm Pitch
? Supports 5-V VCC Operation
? Inputs Accept Voltages to 5.5 V
? Provides Down Translation to VCC
Max tpd of 3.7 ns at 3.3 V
? Low Power Consumption, 10-μA Max ICC
? ±24-mA Output Drive at 3.3 V
? Ioff Supports Live Insertion,
Partial-Power-Down Mode, and
Back-Drive Protection
? Latch-Up Performance Exceeds 100 mA
Per JESD 78, Class II
? ESD Protection Exceeds JESD 22
2000-V Human-Body Model (A114-A)
200-V Machine Model (A115-A)
1000-V Charged-Device Model (C101)
